Polymorphic DSL
search synth, filter, render, points, mixer

perlin(
  scale: 100,
  octaves: 2,
  dimensions: 3,
  seed: 48
)
  .subchain(name: "flow field particles", id: "lkjw") {
    .pointsEmit(stateSize: x1024)
    .flow(
      behavior: chaotic,
      stride: 51,
      strideDeviation: 0.5,
      kink: 5.4
    )
    .pointsRender(
      density: 100,
      intensity: 74.59,
      inputIntensity: 21.46
    )
    .pointsBillboardRender(
      shapeMode: soft,
      depositOpacity: 100,
      pointSize: 33.19,
      sizeVariation: 100,
      seed: 0,
      density: 0.78,
      intensity: 44.72,
      inputIntensity: 18.23
    )
  }
  .blur()
  .write(o0)

navierStokes(
  tex: read(o0),
  zoom: x4,
  iterations: 40,
  smoothing: bSpline4x4,
  speed: 145,
  dyeDecay: 97.52,
  velocityDecay: 100,
  inputForce: 1,
  inputDye: 1,
  inputIntensity: 6.01
)
  .palette(
    index: solaris,
    offset: 25,
    alpha: 0.67
  )
  .lighting(
    normalStrength: 5,
    smoothing: 1.8,
    specularIntensity: 0.7,
    shininess: 130,
    reflection: 21.8,
    refraction: 23,
    aberration: 18.4
  )
  .adjust(brightness: 1.9, contrast: 0.8)
  .subchain(name: "lens effects", id: "dpxp") {
    .temporalAberration(
      redDelay: 4.7,
      greenDelay: 1.8,
      blueDelay: 0,
      _skip: true
    )
    .bloom(taps: 15)
    .lens(displacement: -0.28)
    .vignette(brightness: 0.36, alpha: 0.45)
  }
  .grain(alpha: 0.18, _skip: true)
  .write(o1)

render(o1)
Noisemaker for Rust GPU: wgpu render on Metal, frame at 30 seconds
Noisemaker for Rust GPU rendering the demo program
Download the Cargo project
noisemaker-for-rust-gpu-hero.zip · 2.0 MB · engine source included
Rust
1.88 or newer, with cargo
GPU
Metal on macOS, where the shaders compile with Tint and the port is parity tested. Elsewhere wgpu uses Vulkan, DirectX 12 or OpenGL with naga; those renders are not compared with the reference.
macOS build
git, curl and a C++ compiler (Xcode Command Line Tools)
Network
the first build fetches crates and, on macOS, the pinned Dawn, Abseil and SPIRV-Headers sources (and CMake when 3.22 or newer is not installed). Rendering is offline.
  1. Unzip, open a terminal in the folder, and build the renderer once: cargo build --release --manifest-path engine/Cargo.toml -p nm-render
  2. Render the image above: engine/target/release/nm-render render --dsl program.dsl --out out.png --size 512 --orientation presented --run-seconds 30 --sample-every 30 runs 30 seconds of frames and writes out.t30.png. Without the timed options it writes out.png from 8 frames.
  3. README.md covers the other options, the live viewer and how to edit program.dsl.
